а также протоколы объектного уровня, что дает возможность пользователям иметь прямой доступ к файлам через браузеры по их уникальным URL и уменьшает стоимость размещения приложений из облака.
Обладая богатым набором протоколов и используя в полной мере мощность многоядерных процессоров Intel, семейство EonStor GS3000 демонстрирует не только выдающуюся гибкость, но и невероятные
характеристики в двух конфигурациях: all-flash и гибридной.
В качестве all-flash систем они показывают до 450K IOPS, ширину полосы 11 000 MB/s на блочном
уровне и 4 000 MB/s CIFS. Преобразование протоколов локальных NAS/SAN и облачных сервисов, гибридные функции, как SSD Cache и автоматическое распределение данных по уровням (Tiering), системы EonStor GS3000 обеспечивают исключительные скоростные характеристики на любом уровне обслуживания.
Выдающиеся характеристики и эффективность систем хранения проявляют себя и в интеграции их в облако. Дедубликация и сжатие данныхгарантирует эффективное использование ширины полосы при
перемещение данных в облако и снижает затраты.
|
Host Ports (Dual Host Boards for One Controller)
|
- Onboard Gb/s ports
- Four 1Gb/s iSCSI ports (2 per controller)
- Four 10Gb/s iSCSI ports (2 per controller)
- More host options:
- Eight 6Gb/s SAS ports (4 per controller)
- Eight 12Gb/s SAS ports (4 per controller)
- Sixteen 1Gb/s iSCSI ports (8 per controller)
- Eight or Sixteen 10Gb/s iSCSi ports/ SFP+ (4 or 8 per controller)
- Eight 10Gb/s iSCSI ports/ RJ-45 (4 per controller)
- Sixteen 10Gb/s FCoE ports (8 per controller)
- Sixteen 8Gb/s Fibre Channel ports (8 per controller)
- Eight 16Gb/s Fibre Channel ports (4 per controller)
|
|
Controller
|
Dual redundant controllers
|
|
Protocol Support
|
- File Level Protocol
- CIFS/ SMB
- AFP
- NFS
- FTP
- WebDAV
- Block Level Protocol
- FC
- FCoE
- iSCSI
- SAS
- Object Protocol
-REST API
|
|
Cloud Gateway
|
Support the integration with following cloud providers:
- Amazon S3
- Microsoft Azure
- Google Cloud Platform
- Alibaba AliCloud
|
|
Cache Memory
|
Default DDR4 8GB, up to 16GB, 32GB, 64GB, 128GB or 256GB
** Default installed memory may vary by model, region, and other factors. Contact our sales representatives for details.
|
|
Drive Connectivity
|
- 12Gb/s SAS connectivity
- S.M.A.R.T. support
- Automatic bad-sector reassignment
- Dedicated bandwidth to each connected drive
|
|
Supported Drives
|
- 2.5" SAS SSDs
- 2.5" SATA SSDs*
- 2.5" 10,000RPM SAS drives
- 3.5" 7,200 RPM Nearline SAS drives
- 3.5" 7,200 RPM SATA drives*
*MUX board required when using SATA drives
** For the latest compatibility details, please refer to the Compatibility Matrix.
|
|
Maximum Number of Drives
|
- Per system: 12
- Via JBOD: 432
|
|
Corresponding Expansion Enclosure
|
Please refer to datasheet
|
|
Rack Support
|
2U, 19-inch rackmount
|
|
RAID Functionality
|
- Global, dedicated or enclosure hot-spare
- RAID levels supported : RAID 0, 1 (0+1), 3, 5, 6, 10, 30, 50, 60
- Online expansion by:
- Adding new drives
- Copying and replacing drives with drives of larger capacity
- RAID migration
- Configurable stripe size and write policy per system
- Intelligent drive handling
- In degraded mode: skips irreparable blocks to continue rebuild
- In normal operation: data-block verification and repair
|
|
Data Protection and Data Service
|
- Thin provisioning
- SSD Cache*
- SED (Self-encrypting drives)
- Automated storage tiering*
- Local replication**
- Snapshot
- Volume copy/ mirror
- Remote replication*
- Synchronous or asynchronous for both block level and file level
* Optional
** Available with Standard license and optional Advanced license
|
|
Green Design
|
- 80 PLUS-certified power supplies delivering more than 80% energy efficiency
- Intelligent multi-level drive spin-down
|
|
Availability and Reliability
|
- Redundant, hot-swappable hardware modules
- CacheSafe technology
- Multi-pathing support (EonPath)
- Device mapper support
|
|
Notification
|
Various event notification methods including email, LAN broadcast, fax, SNMP trap and SMS.
|
|
Management
|
- Web-based EonOne management software
- Automated cache flush and caching mode operation per enclosure status
- Telnet and SSH system monitoring via Ethernet
- Module status LED indicators: component presence detection & thermal sensors via I2C bus
- Storage Resource Management to analyze history records of resource usage
- Automate repeatable management tasks by flexible workflow
|
|
Network Configuration
|
- IPv6 support
- Fixed or dynamic IP address
- Dual Gigabit Ethernet with Jumbo Frame
- Port trunking/ NIC teaming/ Link aggregation (IEEE 802.3ad)
- DHCP client
- MPIO, MC/S support
|
|
Access Right Management
|
- User account management
- Group management
- Folder management
- Folder and subfolder access control
- Folder quota
- Comprehensive access control action items
- All Controls, Read, Read and Run, Write, Modify, List
- Support Windows Active Directory Authentication
- Domain Users Login via CIFS/ SMB, AFP, FTP, and file explorer
- LDAP on Linux
|
|
OS Support
|
- Windows Server 2008, 2008 R2, 2012, 2012 R2 (including Hyper-V)
- RedHat Enterprise Linux
- SUSE Linux Enterprise
- Sun Solaris
- Mac OS X
- HP-UX
- IBM AIX
- VMware
- Citrix XenServer
** For the latest OS support details, please contact our sales representatives
|
|
Service and Support
|
- Standard service: 3-year limited hardware/software warranty and 8x5 phone, web, and email support
- Upgrade/Extension service*: replacement part dispatch on the next business day (up to 5 years)
- Advanced Service: 24x7 phone, web and email support + onsite diagnostics on the next business day
- Premium Service: 24x7 phone, web and email support + onsite diagnostics in 4 hours
* Optional
** Service may vary by region
|
|
Power
|
- Power supplies: Two 530W
- AC voltage: 100VAC @ 10A to 240VAC @ 5A with PFC (auto-switching)
- Frequency: 47-63 Hz
|
|
Environmental
|
- Temperature:
- Operating: 0 to 40°C without BBU or CBM / 0 to 35°C with BBU or CBM
- Non-operating: -40 to 60°
- Altitude: Sea level to 3660m (12,000ft) operating / sea level to 12,192m (40,000ft) non-operating
- Relative humidity: 5 to 95% non-condensing, operating and non-operating
|
|
Regulatory
|
- Safety: UL, BSMI, CB, EAC
- Electromagnetic Compatibility: CE, BSMI, FCC, KC
|
|
Dimensions
|
447mm (W) x 88mm (H) x 500mm (D)
**Without chassis ears / protrusions
|
|
Weight
|
21.66kg/ 47.75lbs (without HDDs)
|
|
Package Dimensions
|
780mm (W) x 379mm (H) x 588mm (D)
|
